TM 5-3805-294-24P
0002
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
DESCRIPTION AND USABLE ON
NO. SMR CODE
NSN
CAGEC
PART NUMBER
CODE (UOC)
QTY
GROUP 1810 OPERATORS
ENCLOSURE
FIG. 110. CAB FLOOR PLATE
HARDWARE
PAHZZ
5310-01-475-3812
1J955
24M7346
WASHER,FLAT 11 X 20 X 2 MM ................ 11
1
PAHZZ
5305-01-474-0391
1J955
AT213615
SCREW,MACHINE M10 X 40 ....................... 2
2
PAHZZ
5306-01-584-3156
3PSD7
J781065
BOLT ............................................................. 2
3
PAHZZ
5306-01-240-5171
64678
304017010047
BOLT,MACHINE M10 X 35 ........................... 6
4
PAHZZ
5306-01-585-1553
3PSD7
J781090
BOLT ............................................................. 1
5
END OF FIGURE
0002-251
