TM 5-3805-294-24P
0002
(1)
(2)
(3)
(4)
(5)
(6)
(7)
ITEM
DESCRIPTION AND USABLE ON
NO. SMR CODE
NSN
CAGEC
PART NUMBER
CODE (UOC)
QTY
GROUP 1910 HOOD AND ENGINE
ENCLOSURE
FIG. 130. STORAGE COMPARTMENT
COVER
PAFZZ
5305-01-330-8496
75755
19M7662
SCREW,CAP,HEXAGON H HD, M10 X
1
30 ................................................................ 11
PAFZZ
5310-01-475-3812
1J955
24M7346
WASHER,FLAT 11 X 20 X 2 MM ................ 11
2
PAFZZ
5340-01-585-3625
3PSD7
3092189
COVER,ACCESS .......................................... 1
3
PAFZZ
5340-01-597-3857
3PSD7
DH700234
COVER,STOWAGE COMPT ........................ 1
4
END OF FIGURE
0002-293
