TM 5-3805-294-23-1
0038
Table 1. DTC 157.04 - Fuel Rail Pressure Signal Out of Range Low - Continued.
Test or Inspection
Corrective Action
Malfunction
Measure resistance (Volume
1.
If less than 5 ohms, proceed to
16.
Open Circuit
Malfunction 17.
Between Engine
3, WP 0369) between engine
Wiring Harness
wiring harness connector J03
2.
If greater than 5 ohms, replace
Connector J03
socket G1 (Volume 5,
engine wiring harness.
Socket G1 and
WP 0800, Figure 48) and
(Volume 4, WP 0510) Restore
Engine Wiring
engine wiring harness
machine to original condition
Harness Connector
connector P05 socket 3.
and perform Harness
P05 Socket 3.
(Volume 5, WP 0800, Figure
Diagnostic Mode Test.
57) Note reading.
(Volume 3, WP 0345)
Measure resistance (Volume
1.
If less than 5 ohms, problem
17.
Open Circuit
not found and may have been
Between Engine
3, WP 0369) between engine
missed during
Wiring Harness
wiring harness connector J03
troubleshooting. Reconnect all
Connector J03
socket G2 (Volume 5,
connectors and restart
Socket G2 and
WP 0800, Figure 48) and
procedure at Malfunction 1.
Engine Wiring
engine wiring harness
Harness Connector
connector P05 socket 2.
2.
If greater than 5 ohms, replace
P05 Socket 2.
(Volume 5, WP 0800, Figure
engine wiring harness.
57) Note reading.
(Volume 4, WP 0510) Restore
machine to original condition
and perform Harness
Diagnostic Mode Test.
(Volume 3, WP 0345)
END OF WORK PACKAGE
0038-8
