TM 5-3805-294-23-1
0049
Table 1. DTC 627.01- All Injectors Circuits Have High Resistance - Continued.
Test or Inspection
Corrective Action
Malfunction
14.
Perform Harness Diagnostic
Mode Test. (Volume 3,
WP 0345)
15.
Refresh DTCs. Note if DTC
627.01 is an active DTC.
(Volume 3, WP 0362)
16.
Select Readings and select
Disconnect From Model(s).
(Volume 3, WP 0363)
17.
Select Yes to terminate your
readings connection. (Volume
3, WP 0363)
18.
Turn key switch to OFF
1.
If DTC 627.01 is not an active
position (TM 5-3805-294-10).
DTC, problem corrected.
Restore machine to original
(Volume 5, WP 0794)
condition.
If DTC 627.01 is an active
2.
DTC, it is possible that another
fault exists or that another
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
END OF WORK PACKAGE
0049-10
