TM 5-3805-294-23-1
0070
Table 1. DTC 652.02 - Injector #2 Part Number Invalid - Continued.
Test or Inspection
Corrective Action
Malfunction
6.
Select Connected Calibrations
and select Interactive
Calibrations. (Volume 3,
WP 0340)
7.
Under Interactive Calibrations,
select ECU - (shown with
engine serial number).
(Volume 3, WP 0340)
8.
Under ECU - (shown with
engine serial number), select
Injector Calibration. (Volume
3, WP 0340)
9.
Under ECU - (shown with
engine serial number), select
Change To: (Volume 3,
WP 0340)
10.
Re-enter part number from
data sheet for fuel injector #2
in Change To: line below
Current Value for fuel injector
#2 in Service ADVISOR.
(Volume 3, WP 0340)
11.
Re-enter serial number from
data sheet for fuel injector #2
in Change To: line below
Current Value for fuel injector
#2 in Service ADVISOR.
(Volume 3, WP 0340)
12.
Re-enter calibration code from
data sheet for fuel injector #2
in Change To: line below
Current Value for fuel injector
#2 in Service ADVISOR.
(Volume 3, WP 0340)
13.
Select Next. (Volume 3,
WP 0340)
14.
Verify part number, serial
number, and calibration code
in New Value line below
Current Value for fuel injector
#2 match data sheet. (Volume
3, WP 0340)
0070-7
