TM 5-3805-294-23-1
0075
Table 1. DTC 653.02 - Injector #3 Part Number Invalid - Continued.
Test or Inspection
Corrective Action
Malfunction
11.
Select Readings and select
Disconnect From Model(s).
(Volume 3, WP 0340)
12.
Select Yes to terminate your
readings connection. (Volume
3, WP 0340)
13.
Turn key switch to OFF
1.
If part numbers are the same,
position (TM 5-3805-294-10).
proceed to Malfunction 2.
(Volume 5, WP 0794)
2.
If part numbers are not the
same, proceed to Malfunction
3.
Verify new fuel injector that
1.
If fuel injector is correct fuel
2.
Incorrect Fuel
was installed is correct fuel
injector for the machine,
Injector for
injector for the machine.
proceed to Malfunction 4.
Machine.
2.
If fuel injector is not correct fuel
injector for the machine,
replace fuel injector #3 with
correct fuel injector for the
machine. (Volume 3,
WP 0408) Restore machine to
original condition. Clear and
refresh DTCs. (Volume 3,
WP 0362)
1.
Remove fuel injector #3.
3.
Physical
Verification of Part
(Volume 3, WP 0408)
Number.
0075-3
