TM 5-3805-294-23-1
0002
EQUIPMENT DATA - Continued
Table 6. HYEX Working Ranges.
ITEM DESCRIPTION
MEASUREMENT
SPECIFICATION
1
Maximum Digging reach
Distance
35 ft 6 in. (10810 mm)
2
Maximum Digging reach at Ground
Distance
34 ft 11 in. (10640 mm)
Level
3
Minimum Swing Radius
Radius
11 ft 4 in. (3460 mm)
4
Maximum Cutting Height
Height
34 ft 6 in. (10520 mm)
5
Maximum Dumping Height
Height
24 ft 9 in. (7540 mm)
6
Maximum Digging Depth
Depth
24 ft 7 in. (7490 mm)
7
Maximum Digging Depth (flat bottom)
Depth
24 ft 1 in. (7330 mm)
8
Maximum Vertical Wall
Depth
21 ft 9 in. (6630 mm)
9
Tail Swing Radius
Radius
9 ft 8 in. (2940 mm)
