TM 5-3805-294-23-1
0025
Table 1. DTC 105.00 - Manifold Air Temperature Signal Extremely High - Continued.
Test or Inspection
Corrective Action
Malfunction
Perform air intake leak test.
1.
If air intake gasket leaks,
12.
Air Intake Manifold
replace air intake manifold
Leaks.
(Volume 3, WP 0316)
gasket. (Volume 3, WP 0438)
2.
If air intake clamps are loose or
damaged, replace or tighten
air intake clamps. (Volume 3,
WP 0438) Restore machine to
original condition and operate
engine through normal speed
and load (TM 5-3805-294-10).
(Volume 5, WP 0794) Clear
and refresh DTCs. (Volume 3,
WP 0362)
3.
If air intake gasket does not
leak, proceed to Malfunction
13.
Perform turbocharger
1.
If damaged or faulty, replace
13.
Turbocharger is
inspection. (Volume 3,
turbocharger. (Volume 3,
Damaged or Faulty.
WP 0382)
WP 0452) Restore machine to
original condition and operate
engine through normal speed
and load (TM 5-3805-294-10).
(Volume 5, WP 0794) Clear
and refresh DTCs. (Volume 3,
WP 0362)
2.
If not damaged and not faulty,
replace ECU. (Volume 4,
WP 0508) Restore machine to
original condition and operate
engine through normal speed
and load (TM 5-3805-294-10).
(Volume 5, WP 0794) Clear
and refresh DTCs. (Volume 3,
WP 0362)
END OF WORK PACKAGE
0025-8
