TM 5-3805-294-23-1
0025
Table 1. DTC 105.00 - Manifold Air Temperature Signal Extremely High - Continued.
Test or Inspection
Corrective Action
Malfunction
5.
Select Engine Control Unit
(ECU) Only. (Volume 3,
WP 0363)
6.
Under Connected Data Points,
select ECU - (shown with
engine serial number).
(Volume 3, WP 0363)
7.
Under ECU - (shown with
engine serial number), select
ECU - Data List - All. (Volume
3, WP 0363)
8.
Under ECU - Data List - All,
select Manifold Air
Temperature. (Volume 3,
WP 0363)
9.
Monitor MAT sensor
temperature. Temperature
should closely match ambient
air temperature. Note reading.
10.
When finished monitoring,
select Readings and select
Disconnect From Model(s).
(Volume 3, WP 0363)
11.
Select Yes to terminate your
readings connection. (Volume
3, WP 0363)
0025-5
