TM 5-3805-294-23-1
0024
Table 1. DTC 100.31 - Engine Oil Pressure Detected With Engine Stopped - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Verify the key switch is in the
6.
Check For DTC
OFF position (TM
100.04 Active
5-3805-294-10). (Volume 5,
Status With Engine
Wiring Harness
WP 0794)
Connector J03
Disconnected.
2.
Disconnect engine wiring
harness connector J03 from
ECU. (Volume 5, WP 0800,
Figure 48)
3.
Turn the key switch to the ON
position, but DO NOT START
ENGINE (TM 5-3805-294-10).
(Volume 5, WP 0794)
4.
Refresh DTCs. Many new
DTCs will be active, only note
if DTC 100.04 is an active
DTC. (Volume 3, WP 0362)
5.
Turn the key switch to the OFF
1.
If DTC 100.04 is an active DTC
position (TM 5-3805-294-10).
and engine oil pressure sensor
has not been changed, replace
(Volume 5, WP 0794)
engine oil pressure sensor.
(Volume 3, WP 0417)
If DTC 100.04 is an active
2.
DTC, problem was not found
and may have been missed
during troubleshooting. Install
engine oil pressure sensor.
(Volume 3, WP 0417) Restart
procedure at Malfunction 4.
3.
If DTC 100.04 is not an active
DTC, replace ECU. (Volume 4,
WP 0508) Restore machine to
original condition and perform
Harness Diagnostic Mode
Test. (Volume 3, WP 0345)
END OF WORK PACKAGE
0024-4
