TM 5-3805-294-23-1
0030
TROUBLESHOOTING PROCEDURE
Table 1. DTC 108.02 - Barometric Air Pressure Signal Invalid.
Test or Inspection
Corrective Action
Malfunction
Inspect ECU air vent for
1.
If air vent is clogged, remove
ECU Air Vent
clogged or damaged air vent.
foreign objects or debris.
Clogged or
Perform Harness Diagnostic
Damaged.
(Volume 5, WP 0800, Figure
Mode Test. (Volume 3,
146)
WP 0345)
2.
If air vent is damaged, replace
ECU. (Volume 4, WP 0508)
Restore machine to original
condition.
3.
If air vent is not damaged or
clogged, replace ECU.
(Volume 4, WP 0508) Restore
machine to original condition.
END OF WORK PACKAGE
0030-2
