TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 110.00 - COOLANT TEMPERATURE SIGNAL EXTREMELY HIGH
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0410
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0412
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0469
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0470
Test Set, MSD Electronic Systems
Volume 3, WP 0471
(Volume 5, WP 0796, Table 2, Item 116)
Volume 3, WP 0483
Volume 3, WP 0484
Volume 4, WP 0508
Personnel Required
Volume 4, WP 0510
Construction Equipment Repairer 91L (2)
Volume 4, WP 0511
Volume 5, WP 0800
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Equipment Condition
Machine safely parked and shut down
Volume 2, WP 0310
(TM 5-3805-294-10). (Volume 5, WP 0794)
Volume 3, WP 0326
Test Equipment Setup for MSD and Service
Volume 3, WP 0362
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0363
Troubleshooting Sequence
DTC 110.00
When DTC is Displayed
When the engine has been running three minutes and the error is active.
Related Information
The engine has to be running for three minutes before the code is set.
1569.31 is set when this code is active and engine has not shut down.
1109.31 is set 30 seconds before the ECU shuts down the engine.
1110.31 is set if the shutdown feature is enabled.
Alarm Level
Stop.
Control Unit Response
Maximum engine power is derated up to 60 percent.
0031-1
