TM 5-3805-294-23-1
0031
Table 1. DTC 110.00 - Coolant Temperature Signal Extremely High - Continued.
Test or Inspection
Corrective Action
Malfunction
6.
Under Connected Data Points,
select ECU - (shown with
engine serial number).
(Volume 3, WP 0363)
7.
Under ECU - (shown with
engine serial number), select
ECU - Data List - All. (Volume
3, WP 0363)
8.
Under ECU - Data List - All,
select Coolant Temperature.
(Volume 3, WP 0363)
9.
Monitor engine coolant
temperature sensor
temperature. Temperature
should closely match ambient
air temperature. If necessary,
let sensor cool down to
ambient temperature. Note
reading.
10.
When finished monitoring,
select Readings and select
Disconnect From Model(s).
(Volume 3, WP 0363)
11.
Select Yes to terminate your
readings connection. (Volume
3, WP 0363)
0031-7
