TM 5-3805-294-23-1
0031
Table 1. DTC 110.00 - Coolant Temperature Signal Extremely High - Continued.
Test or Inspection
Corrective Action
Malfunction
Perform cooling system
1.
If faulty, repair cooling
19.
Cooling System
Faulty.
check. (Volume 3, WP 0326)
system. (Volume 3, WP 0326)
Restore machine to original
condition and operate engine
through normal speed and
load. (TM 5-3805-294-10)
(Volume 5, WP 0794) Clear
and refresh DTCs. (Volume 3,
WP 0362)
2.
If not faulty, proceed to
Malfunction 20.
Perform troubleshooting
1.
If problem corrected during
20.
Cooling System
procedure Engine Coolant
previous troubleshooting
Components
Temperature Above Normal.
Faulty.
procedure, (WP 0114) restore
machine to original condition
and operate engine through
normal speed and load. (TM
5-3805-294-10) (Volume 5,
WP 0794) Clear and refresh
DTCs. (Volume 3, WP 0362)
2.
If problem not corrected during
previous troubleshooting
procedure, (WP 0114) replace
ECU. (Volume 4, WP 0508)
END OF WORK PACKAGE
0031-10
