TM 5-3805-294-23-1
0051
Table 1. DTC 629.13 - Engine Control Unit (ECU) Boot Block Error - Continued.
Test or Inspection
Corrective Action
Malfunction
4.
Disconnect Service
ADVISOR. (Volume 3,
WP 0375)
5.
Turn key switch to OFF
position (TM 5-3805-294-10).
(Volume 5, WP 0794)
6.
Wait 5 minutes, and turn key
switch to ON position, but DO
NOT START ENGINE (TM
5-3805-294-10). (Volume 5,
WP 0794)
7.
Connect Service ADVISOR.
(Volume 3, WP 0375)
8.
Clear and refresh DTC's.
1.
If DTC 629.13 - ECU boot
block error does not appear as
(Volume 3, WP 0362)
an active DTC, problem
corrected.
If DTC 629.13 - ECU boot
2.
block error does appear as an
active DTC, it is possible that
another fault exists or that
another troubleshooting
procedure applies. If this was
the first time through this
procedure, restart procedure
at Malfunction 1.
END OF WORK PACKAGE
0051-3/4 blank
