TM 5-3805-294-23-1
0091
Table 1. DTC 656.05 - Injector #6 Circuit Has High Resistance - Continued.
Test or Inspection
Corrective Action
Malfunction
Measure resistance (Volume
1.
If less than 2 ohms, proceed to
7.
Open Circuit
Malfunction 8.
Between Engine
3, WP 0369) between engine
Wiring Harness
wiring harness connector J01
2.
If greater than 2 ohms, replace
Connector J01
socket C1 (Volume 5,
engine wiring harness.
Socket C1 and
WP 0800, Figure 46) and
(Volume 4, WP 0510) Restore
Engine Wiring
engine wiring harness
machine to original condition
Harness Connector
connector C01 socket 12.
and perform Harness
C01 Socket 12.
(Volume 5, WP 0800, Figure
Diagnostic Mode Test.
32) Note reading.
(Volume 3, WP 0345)
Measure resistance (Volume
1.
If less than 2 ohms, replace
8.
Open Circuit
Between Engine
3, WP 0369) between engine
ECU. (Volume 4, WP 0508)
Wiring Harness
wiring harness connector J01
Restore machine to original
Connector J01
socket G2 (Volume 5,
condition and perform
Socket G2 and
Harness Diagnostic Mode
WP 0800, Figure 46) and
Engine Wiring
engine wiring harness
Test. (Volume 3, WP 0345)
Harness Connector
connector C01 socket 9.
2.
If greater than 2 ohms, replace
C01 Socket 9.
(Volume 5, WP 0800, Figure
engine wiring harness.
32) Note reading.
(Volume 4, WP 0510) Restore
machine to original condition
and perform Harness
Diagnostic Mode Test.
(Volume 3, WP 0345)
END OF WORK PACKAGE
0091-4
