TM 5-3805-294-23-1
0094
Table 1. DTC 656.13 - Injector #6 Calibration Fault - Continued.
Test or Inspection
Corrective Action
Malfunction
15.
Verify part number, serial
number, and calibration code
in New Value line below
Current Value for fuel injector
#6 match data sheet. (Volume
3, WP 0340)
16.
After Calibration Complete
appears, select OK. (Volume
3, WP 0340)
17.
Select Exit and then select
Yes. (Volume 3, WP 0340)
18.
Select Reading and select
Disconnect From Model(s).
(Volume 3, WP 0340)
19.
Select Yes to terminate your
readings connection. (Volume
3, WP 0340)
20.
Turn key switch to OFF
position for a minimum of 90
seconds to complete the
calibration. (TM
5-3805-294-10). (Volume 5,
WP 0794)
21.
Clear and refresh DTCs. Note
1.
If DTC 656.13 is still an active
if DTC 656.13 is still an active
DTC, it is possible that another
fault exists or that another
DTC. (Volume 3, WP 0362)
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
2.
If DTC 656.13 is not an active
DTC, problem corrected.
END OF WORK PACKAGE
