TM 5-3805-294-23-1
0104
Table 1. DTC 1638.09 - Hydraulic Oil Temperature Message Not Received or Timed Out - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Connect all connectors except
64.
connector X20. (Volume 5,
Between Connector
X20 Sockets 6 and 7
WP 0800, Figure 87)
Out Of Range.
2.
Measure resistance (Volume
1.
If between 110 - 130 ohms,
proceed to Malfunction 65.
3, WP 0369) between
connector X20 sockets 7 and
2.
If not between 110 - 130 ohms,
6. (Volume 5, WP 0800,
replace CAN terminating
Figure 87) Note reading.
resistor. (Volume 4,
WP 0506) Restore machine to
original condition. Clear and
refresh DTCs. (Volume 3,
WP 0362)
1.
Connect connector X20 to
65.
Check DTC 1638.09
monitor controller. (Volume 5,
For Active Status.
WP 0800, Figure 87)
2.
Turn key switch to ON position,
but DO NOT START ENGINE
(TM 5-3805-294-10). (Volume
5, WP 0794)
3.
Clear and refresh DTCs. Note
if DTC 1638.09 is still active.
(Volume 3, WP 0362)
4.
Turn key switch to OFF
1.
If DTC 1638.09 is still active,
position (TM 5-3805-294-10).
replace monitor controller.
(Volume 5, WP 0794)
(Volume 4, WP 0518) Restore
machine to original condition.
Clear and refresh DTCs.
(Volume 3, WP 0362)
2.
If DTC 1638.09 is not active,
problem corrected.
END OF WORK PACKAGE
0104-20
