TM 5-3805-294-23-4
0612
REMOVAL - Continued
3
1
2
HYEX00777
Figure 1. Disconnect Horn Wiring.
2.
Disconnect ground wiring harness (Figure 1, Item 3) from horn (Figure 1, Item 2).
3.
Remove nut (Figure 2, Item 4), washer (Figure 2, Item 5), ground wiring harness (Figure 2, Item 3), and horn
(Figure 2, Item 2) from stud (Figure 2, Item 6).
