TM 5-3805-294-23-4
0611
ASSEMBLY - Continued
14
8
13
12
HYEX01664
Figure 12. Tool Box Lid Assembly Installation.
END OF TASK
INSTALLATION
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
1.
Install tool box (Figure 13, Item 8) assembly to frame (Figure 13, Item 11) with five washers (Figure 13, Item
10) and screws (Figure 13, Item 9).
