TM 5-3805-294-23-1
0043
Table 1. DTC 174.03 - Fuel Temperature Signal Out of Range High - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Replace sockets in engine
14.
Engine Wiring
wiring harness connector T05
Harness Connector
T05 Sockets and
(Volume 4, WP 0511) or
Fuel Temperature
replace engine wiring
Sensor Are Faulty.
harness. (Volume 4,
WP 0510)
2.
Replace fuel temperature
sensor. (Volume 3, WP 0430)
3.
Turn the key switch to the ON
position, but DO NOT START
ENGINE (TM 5-3805-294-10).
(Volume 5, WP 0794)
4.
Refresh DTCs. Note if DTC
174.03 is still active DTC.
(Volume 3, WP 0362)
5.
Turn the key switch to the OFF
1.
If DTC 174.03 is still active, it is
position (TM 5-3805-294-10).
possible that another fault
exists or that another
(Volume 5, WP 0794)
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
If DTC 174.03 is not active,
2.
problem corrected. Restore
machine to original condition.
END OF WORK PACKAGE
0043-8
