TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 651.13 - INJECTOR #1 CALIBRATION FAULT
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0340
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0362
Accessory Kit, MSD Electronic Equipment
Volume 4, WP 0508
(Volume 5, WP 0796, Table 2, Item 2)
Test Set, MSD Electronic Systems
Equipment Condition
(Volume 5, WP 0796, Table 2, Item 116)
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
Personnel Required
Test Equipment Setup for MSD and Service
Construction Equipment Repairer 91L (1)
ADVISOR. (Volume 3, WP 0375)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Troubleshooting Sequence
DTC 651.13
When DTC is Displayed
During an injector programming event.
Related Information
The ECU detects an incorrect calibration code was programmed into the ECU. The engine performance may be
drastically effected.
Alarm Level
Warning.
Control Unit Response
The ECU will attempt to run the engine normally.
0069-1
