TM 5-3805-294-23-1
0073
Table 1. DTC 652.07 - Injector #2 Not Responding - Continued.
Test or Inspection
Corrective Action
Malfunction
2.
Perform Cylinder Misfire Test
1.
If tests confirm faulty injector,
replace electronic fuel injector
(Volume 3, WP 0330) and
record results.
#2. (Volume 3, WP 0408)
Restore machine to original
condition. Start engine and
allow engine to idle (TM
5-3805-294-10). (Volume 5,
WP 0794) Clear and refresh
DTCs. (Volume 3, WP 0362)
2.
If tests do not confirm faulty
injector, proceed to
Malfunction 3.
Perform Injector Flow Rate
1.
If amount of fuel collected is 24
3.
Excessive Fuel
oz (0.7 L), replace ECU.
During Injector
Test (Volume 3, WP 0341)
Flow Rate Test.
and record results.
(Volume 4, WP 0508) Restore
machine to original condition.
Start engine and allow engine
to idle (TM 5-3805-294-10).
(Volume 5, WP 0794) Clear
and refresh DTCs. (Volume 3,
WP 0362)
2.
If amount of fuel collected is
more than 24 oz (0.7 L),
replace electronic fuel injector
#2. (Volume 3, WP 0408)
Restore machine to original
condition. Start engine and
allow engine to idle (TM
5-3805-294-10). (Volume 5,
WP 0794) Clear and refresh
DTCs. (Volume 3, WP 0362)
END OF WORK PACKAGE
0073-3/4 blank
