TM 5-3805-294-23-1
FIELD MAINTENANCE
ENGINE EMITS EXCESSIVE WHITE EXHAUST SMOKE
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0330
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0346
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0362
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0407
Test Set, MSD Electronic Systems
Volume 3, WP 0408
(Volume 5, WP 0796, Table 2, Item 116)
Volume 3, WP 0410
Volume 3, WP 0450
Volume 4, WP 0508
Personnel Required
Volume 5, WP 0800
Construction Equipment Repairer 91L (2)
Equipment Condition
References
Machine safely parked and shut down (TM
TM 5-3805-294-10 (Volume 5, WP 0794)
5-3805-294-10). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
Volume 3, WP 0321
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0328
Volume 3, WP 0329
TROUBLESHOOTING PROCEDURE
Table 1. Engine Emits Excessive White Exhaust Smoke.
Test or Inspection
Corrective Action
Malfunction
Were you referred to this test
1.
If you were referred to this test,
1.
DTC Referral.
while performing the
proceed to Malfunction 3.
diagnostic procedures for a
2.
If you were not referred to this
DTC?
test, proceed to Malfunction 2.
1.
Turn key switch to ON position,
2.
Check For Active
but DO NOT START ENGINE
DTCs.
(TM 5-3805-294-10). (Volume
5, WP 0794)
2.
Read DTCs. Note all active
DTCs. (Volume 3, WP 0362)
0118-1
