TM 5-3805-294-23-1
0120
Table 1. Engine Misfires - Runs Irregularly - Continued.
Test or Inspection
Corrective Action
Malfunction
11.
When finished monitoring,
select Readings and select
Disconnect From Model(s).
(Volume 3, WP 0363)
12.
Select Yes to terminate your
readings connection. (Volume
3, WP 0363)
13.
Shut down engine and turn key
1.
If the data points were as
switch to OFF position (TM
indicated, proceed to
5-3805-294-10). (Volume 5,
Malfunction 18.
WP 0794)
2.
If the data points were not as
indicated, proceed to
Malfunction 16.
1.
Disconnect engine wiring
16.
Check For Crank
harness connector X01 from
Sensor Pattern
crankshaft position sensor
Problem.
(Volume 5, WP 0800, Figure
82) and secure connector
away from rotating
components.
2.
Turn key switch to ON position;
START ENGINE (TM
5-3805-294-10). (Volume 5,
WP 0794)
3.
Operate engine at speed and
load where problem occurs
(TM 5-3805-294-10). (Volume
5, WP 0794) Note engine
performance.
4.
Shut down engine and turn key
switch to OFF position (TM
5-3805-294-10). (Volume 5,
WP 0794)
5.
Reconnect engine wiring
1.
If engine performance was
harness connector X01 to
restored, discontinue this
crankshaft position sensor.
troubleshooting procedure and
perform procedure for DTC
(Volume 5, WP 0800, Figure
82)
637.02 (WP 0047) as though
DTC was active.
2.
If engine performance was not
restored, proceed to
Malfunction 17.
0120-9
