TM 5-3805-294-23-1
FIELD MAINTENANCE
ENGINE OIL PRESSURE HIGH
INITIAL SETUP:
Tools and Special Tools
References (cont.)
Tool Kit, General Mechanic's: Automotive
Volume 2, WP 0310
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0355
Volume 3, WP 0410
Volume 3, WP 0411
Personnel Required
Construction Equipment Repairer 91L (2)
Equipment Condition
Machine safely parked and shut down (TM
References
5-3805-294-10). (Volume 5, WP 0794)
TM 5-3805-294-10 (Volume 5, WP 0794)
TROUBLESHOOTING PROCEDURE
Table 1. Engine Oil Pressure High.
Malfunction
Test or Inspection
Corrective Action
Check engine oil level.
1.
If engine oil level is too high,
1.
Engine Oil Level
drain oil to proper level.
Too High.
(Volume 2, WP 0310)
(Volume 3, WP 0411) Restore
machine to original condition.
2.
If engine oil level is correct,
proceed to Malfunction 2.
1.
Change engine oil and engine
2.
Engine Oil Filter
and Engine Oil Are
oil filter. (Volume 3, WP 0411)
Faulty.
2.
Select Engine Oil Pressure
under the monitor Service
Menu. (Volume 3, WP 0355)
3.
Start engine and observe
engine oil pressure on monitor
(TM 5-3805-294-10). Note if
engine oil pressure exceeds
496 kPa (72 psi). (Volume 5,
WP 0794)
0121-1
