TM 5-3805-294-23-1
0122
Table 1. Engine Oil Pressure Low - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Remove oil cooler. (Volume 3,
3.
Oil Cooler Faulty.
WP 0415)
2.
Visually inspect oil cooler for
1.
If damaged, replace oil cooler
damage.
(Volume 3, WP 0415) and oil
filter. (Volume 3, WP 0411)
Restore machine to original
condition.
2.
If not damaged, replace oil
filter (Volume 3, WP 0411) and
then proceed to Malfunction 4.
1.
Remove oil pan. (Volume 3,
4.
Clogged Oil Pump
Screen or Cracked
WP 0440)
Pickup Tube.
2.
Visually inspect oil pump
1.
If screen has debris, remove
screen for debris and pickup
debris.
tube for damage. (Volume 3,
2.
If pickup tube is damaged,
WP 0418)
replace pickup tube. (Volume
3, WP 0418) Restore machine
to original condition.
3.
If no debris and pickup tube is
not damaged, proceed to
Malfunction 5.
1.
Remove oil pump. (Volume 3,
5.
Oil Pump Has
Damage.
WP 0418)
2.
Visually inspect oil pump for
1.
If damaged, replace oil pump.
damage.
(Volume 3, WP 0418) Restore
machine to original condition.
2.
If not damaged, replace
engine. (Volume 3, WP 0410)
Restore machine to original
condition.
END OF WORK PACKAGE
0122-2
