TM 5-3805-294-23-1
FIELD MAINTENANCE
ENGINE WILL NOT CRANK
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0369
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0410
Multimeter, Digital
Volume 3, WP 0449
(Volume 5, WP 0796, Table 2, Item 77)
Volume 4, WP 0494
Probe Set, Standard
Volume 4, WP 0496
(Volume 5, WP 0796, Table 2, Item 91)
Volume 4, WP 0503
Volume 4, WP 0504
Volume 4, WP 0505
Materials/Parts
Volume 4, WP 0508
Wire, Jumper
Volume 4, WP 0509
(Volume 5, WP 0792)
Volume 4, WP 0511
Volume 4, WP 0516
Personnel Required
Volume 4, WP 0525
Construction Equipment Repairer 91L (2)
Volume 4, WP 0527
Volume 4, WP 0528
Volume 4, WP 0529
References
Volume 4, WP 0566
TM 5-3805-294-10 (Volume 5, WP 0794)
Volume 4, WP 0578
Volume 2, WP 0169
Volume 4, WP 0593
Volume 2, WP 0170
Volume 5, WP 0800
Volume 2, WP 0185
Volume 3, WP 0318
Volume 3, WP 0327
Equipment Condition
Volume 3, WP 0333
Machine safely parked and shut down (TM
Volume 3, WP 0365
5-3805-294-10). (Volume 5, WP 0794)
TROUBLESHOOTING PROCEDURE
Table 1. Engine Will Not Crank.
Test or Inspection
Corrective Action
Malfunction
Verify position of pilot shutoff
1.
If in LOCK (up) position,
1.
Pilot Shutoff Lever
lever (TM 5-3805-294-10).
proceed to Malfunction 2.
Not Positioned
Correctly.
(Volume 5, WP 0794)
2.
If in UNLOCKED (down)
position, move lever to LOCK
(up) position (TM
5-3805-294-10). (Volume 5,
WP 0794)
1.
Remove battery covers.
2.
Battery Terminals
Are Damaged or
(Volume 4, WP 0496)
Loose.
0123-1
