TM 5-3805-294-23-4
FIELD MAINTENANCE
APPLY VACUUM TO HYDRAULIC RESERVOIR
INITIAL SETUP:
References
Tools and Special Tools
TM 5-3805-294-24P: Fig. 59 (Volume 5,
Tool Kit, General Mechanic's: Automotive
WP 0794)
(Volume 5, WP 0796, Table 2, Item 119)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Cap and Plug Set (Volume 5, WP 0796, Table 2,
WP 0794)
Item 55)
Gloves, Rubber (Volume 5, WP 0796, Table 2,
Item 55)
Equipment Condition
Goggles, Industrial (Volume 5, WP 0796, Table 2,
Machine safely parked and shut down
Item 58)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Tee, Hose (9/16-18 F Sw 37 x 7/16-20 M 37 x
Hydraulic system pressure relieved. (Volume 5,
9/16-18 M 37) (Volume 5, WP 0796, Table 2,
WP 0767)
Item 113)
Center top cover removed. (WP 0589)
Vacuum Pump Kit (Volume 5, WP 0796, Table 2,
Item 122)
Time to Complete
0.8 Hour(s)
Materials/Parts
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
34)
Personnel Required
Construction Equipment Repairer 91L (1)
CONNECT VACUUM PUMP
WARNING
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry
and tools can catch on equipment, contact positive electrical circuits, and cause a direct
short, severe burns, or electrical shock. Failure to comply may result in injury or death to
personnel.
