TM 5-3805-294-24P
0002
2
4
3
TRANSPORATION DATA
GROSSWEIGHT
-
60,000LB.
EQUIPMENTTIEDOWNDESIGNLIMITLOAD
-
LIFTINGDESIGNLIMITLOAD
-
-
4
NO.OFSLINGSREQUIRED
LENGTHOFSLINGS
-
12FT.
1212 MM [47.5 IN.]
EQUIPMENTTIEDOWNPROVISIONS
LIFTINGPROVISIONS
CENTER OF
SWINGCENTERLINE
GRAVETY
1212 MM [47.5 IN.]
44 MM [1.7 IN.]
240D
LCR
1
LIFT
5
6
FUEL TANK SUMP
ENGINE OIL
WATER DRAIN
SAMPLE VALVE
Drain water and sediment from fuel
tank every 50 hours or weekly.
Allow water to settle to tank bottom
HYD
before draining.
It may be possible when valve is
OIL
opened that fuel may drain out at
first. Wait several seconds to allow
SAMPLE
U. S. ARMY
enough time for water to drain
through hose.
MODEL 240DLCR
SER.
FF240DR605003
VALVE
Drain water and sediment into
MO. OF MANUTACTURE
OCTOBER 2009
USAREGISTRATION NO.
3805-01-573-0677
container and dispose of properly.
NSN 3805-01-573-0677
CONT. NO.
W56HZV-09-D-0064
T247868
SHIPPING WT. 66,000
SHIPPING WT.
OVERALL HEIGHT
122 IN. WIDTH
133 IN. LENGTH
399
IN.
WARRANTY-START DATE:
10
6 MO. - BASE UNIT
MFD.
DEERE & COMPANY
BY
7, 8
11
9
3
1
240D
LCR
5
HYEX01128
Figure 72. LABELS AND DECALS (Sheet 1 of 3)
0002-154
