TM 5-3805-294-23-1
FIELD MAINTENANCE
CRACKED TRACK LINK
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0390
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0400
References
Equipment Condition
Machine safely parked and shut down
TM 5-3805-294-10 (Volume 5, WP 0794)
(TM 5-3805-294-10). (Volume 5, WP 0794)
TROUBLESHOOTING PROCEDURE
Table 1. Cracked Track Link.
Test or Inspection
Corrective Action
Malfunction
Check track sag (TM
1.
If track sag is within
1.
Incorrect Track
5-3805-294-10). (Volume 5,
specification, proceed to
Tension
Malfunction 2.
Adjustment.
WP 0794)
2.
If track sag is not within
specification, replace track
chain. (Volume 3, WP 0390)
Visually inspect sprocket for
1.
If damaged, replace sprocket
2.
Sprocket Damaged.
damage. (Volume 3,
(Volume 3, WP 0400) and
WP 0400)
replace track chain. (Volume 3,
WP 0390)
2.
If sprocket is not damaged,
proceed to Malfunction 3.
0007-1
