TM 5-3805-294-23-1
FIELD MAINTENANCE
EXCESSIVE OIL LEAKAGE FROM CARRIER ROLLERS
INITIAL SETUP:
References
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0387
(Volume 5, WP 0796, Table 2, Item 119)
Volume 5, WP 0800
Socket Driver, 3/8" Drive, Chrome, Hex 6 mm
(Volume 5, WP 0796, Table 2, Item 55)
Equipment Condition
Wrench, Torque, 20-100 lb-ft (27-136 Nm),
Machine safely parked and shut down
3/8 in. Drive (Volume 5, WP 0796, Table 2,
(TM 5-3805-294-10). (Volume 5, WP 0794)
Item 127)
TROUBLESHOOTING PROCEDURE
Table 1. Excessive Oil Leakage From Carrier Rollers.
Test or Inspection
Corrective Action
Malfunction
Visually inspect carrier roller
1.
If leaking, tighten drain plug to
Oil Leaking From
drain plug for leakage.
22 lb-ft (30 Nm). (Volume 5,
Carrier Roller Drain
Plug.
(Volume 5, WP 0800, Figure
WP 0800, Figure 236)
236)
2.
If not leaking, replace carrier
roller. (Volume 3, WP 0387)
Restore machine to original
condition.
END OF WORK PACKAGE
0008-1/2 blank
