TM 5-3805-294-23-1
FIELD MAINTENANCE
TIGHT TRACK CHAIN
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0388
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0400
References
Equipment Condition
Machine safely parked and shut down
TM 5-3805-294-10 (Volume 5, WP 0794)
(TM 5-3805-294-10). (Volume 5, WP 0794)
TROUBLESHOOTING PROCEDURE
Table 1. Tight Track Chain.
Test or Inspection
Corrective Action
Malfunction
Visually inspect sprocket area
1.
If debris found, remove debris
1.
Debris Stuck In
for debris. (Volume 3,
from sprocket. (Volume 3,
Sprocket.
WP 0400)
WP 0400)
2.
If debris not found, proceed to
Malfunction 2.
Check track sag (TM
1.
If track sag is not within
2.
Incorrect Track
5-3805-294-10). (Volume 5,
specification, adjust track
Tension
tension (TM 5-3805-294-10).
Adjustment.
WP 0794)
(Volume 5, WP 0794)
2.
If track sag is within
specification, problem not
found and may have been
missed during previous
troubleshooting procedures.
Restart procedure at
Malfunction 1. If problem still
exists after all troubleshooting
procedures are repeated,
replace track chain adjuster.
(Volume 3, WP 0388)
END OF WORK PACKAGE
