TM 5-3805-294-23-1
0041
TROUBLESHOOTING PROCEDURE
Table 1. DTC 158.17 - Engine Control Unit (ECU) Power Down Error.
Test or Inspection
Corrective Action
Malfunction
1.
Turn key switch to ON position,
1.
DTC 158.17 - ECU
but DO NOT START ENGINE
Power Down Error
(TM 5-3805-294-10). (Volume
is an Active DTC.
5, WP 0794)
2.
Note all DTC's and there
occurrence count.
3.
Clear and refresh DTC's.
(Volume 3, WP 0362)
4.
Disconnect Service
ADVISOR. (Volume 3,
WP 0375)
5.
Turn key switch to OFF
position (TM 5-3805-294-10).
(Volume 5, WP 0794)
6.
Wait 5 minutes, then turn key
switch to ON position, but DO
NOT START ENGINE (TM
5-3805-294-10). (Volume 5,
WP 0794)
7.
Connect Service ADVISOR.
(Volume 3, WP 0375)
8.
Clear and refresh DTC's.
1.
If DTC 158.17 does not appear
as a stored or active DTC, turn
(Volume 3, WP 0362)
key switch to OFF position (TM
5-3805-294-10) (Volume 5,
WP 0794) then disconnect
Service ADVISOR. (Volume 3,
WP 0375)
2.
If DTC 158.17 does appear as
a stored or active DTC, turn
key switch to OFF position (TM
5-3805-294-10) (Volume 5,
WP 0794) then proceed to
Malfunction 2.
1.
Replace ECU. (Volume 4,
2.
ECU is Faulty.
WP 0508) Restore machine to
original condition.
0041-2
