TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 174.00 - FUEL TEMPERATURE SIGNAL EXTREMELY HIGH
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0371
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0430
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0431
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0437
Test Set, MSD Electronic Systems
Volume 3, WP 0470
(Volume 5, WP 0796, Table 2, Item 116)
Volume 3, WP 0477
Volume 4, WP 0508
Volume 4, WP 0510
Personnel Required
Volume 4, WP 0511
Construction Equipment Repairer 91L (2)
Volume 4, WP 0521
Volume 5, WP 0800
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Equipment Condition
Machine safely parked and shut down
Volume 3, WP 0343
(TM 5-3805-294-10). (Volume 5, WP 0794)
Volume 3, WP 0362
Test Equipment Setup for MSD and Service
Volume 3, WP 0363
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0366
Troubleshooting Sequence
DTC 110.00
DTC 105.00 or 105.16
DTC 174.00
When DTC is Displayed
When the engine is ON and the error is active.
Related Information
The ECU senses a fuel temperature of 212F (100C).
The engine has to be running for three minutes for the code to set. DTC 1569.31 is set when this code is active and
engine has not shut down.
DTC 1110.31 is set if the shutdown feature is enabled.
DTC 1109.31 is set 30 seconds before the ECU shuts down the engine.
Alarm Level
Stop.
0042-1
