TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 1136.00 - ENGINE CONTROL UNIT (ECU) TEMPERATURE SIGNAL EXTREMELY HIGH
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0362
(Volume 5, WP 0796, Table 2, Item 119)
Volume 4, WP 0508
Accessory Kit, MSD Electronic Equipment
Volume 5, WP 0800
(Volume 5, WP 0796, Table 2, Item 2)
Test Set, MSD Electronic Systems
Equipment Condition
(Volume 5, WP 0796, Table 2, Item 116)
Machine safely parked and shut down (TM
5-3805-294-10). (Volume 5, WP 0794)
Personnel Required
Test Equipment Setup for MSD and Service
Construction Equipment Repairer 91L (2)
ADVISOR. (Volume 3, WP 0375)
References
TM 5-3805-294-10 (Volume 5, WP 0794)
Troubleshooting Sequence
All XXXXXX.06 codes
DTC 611.04
DTC 1136.00
Related Information
The ECU senses an internal ECU temperature of 275F (135C) on OEM engines.
Alarm Level
Stop.
Control Unit Response
The ECU limits the engine to 1200 RPMs.
0096-1
