TM 5-3805-294-23-1
0102
Table 1. DTC 1347.07 - Fuel Rail Pressure Actual To Desired Mismatch - Continued.
Test or Inspection
Corrective Action
Malfunction
2.
Reconnect engine wiring
harness connector P05 to fuel
rail pressure sensor. (Volume
5, WP 0800, Figure 57)
3.
Perform High-Pressure Fuel
1.
If fault found during test, repair
Supply System Test.
fault found in High-Pressure
Fuel Supply System Test.
(WP 0130) Restore machine
to original condition and
perform Harness Diagnostic
Mode Test. (Volume 3,
WP 0345)
2.
If no fault found during test, it is
possible that another fault
exists or that another
troubleshooting procedure
applies. If this was the first time
through this procedure, restart
procedure at Malfunction 1.
END OF WORK PACKAGE
0102-5/6 blank
