TM 5-3805-294-23-4
0521
CONNECT - Continued
Batteries produce explosive gases. Do not smoke or use open flame near batteries. Do not
allow hot, sparking, or glowing objects near batteries. If batteries are giving off gases, the
presence of heat, flame, or spark may cause fire and/or explosion. Failure to comply may
result in injury or death to personnel.
Wear proper eye protection, gloves, and an apron when working near batteries. Failure to
comply may result in injury or death to personnel.
1.
Install negative battery terminal clamp (Figure 3, Item 7) to negative battery terminal (Figure 3, Item 8).
7
6
8
5
HYEX00072
Figure 3. Negative Battery Cable Reconnect.
2.
Tighten nut (Figure 3, Item 5) on screw (Figure 3, Item 6) to negative battery terminal clamp (Figure 3, Item
7).
