TM 5-3805-294-23-4
FIELD MAINTENANCE
MUFFLER COVER REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
(Volume 5, WP 0796, Table 2, Item 119)
Center top cover removed. (WP 0589)
Right side top cover removed. (WP 0604)
Materials/Parts
Locknut (Volume 5, WP 0798, Table 1, Item 20)
Time to Complete
Qty: 4
1.5 Hour(s)
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 58, Fig. 132, Fig. 134
(Volume 5, WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
1.
Remove four locknuts (Figure 1, Item 1), eight washers (Figure 1, Item 2), four screws (Figure 1, Item 3), and
coolant heater (Figure 1, Item 4) from muffler cover (Figure 1, Item 5). Discard locknuts.
0600-1
