TM 5-3805-294-23-4
0613
INSTALLATION - Continued
78
9
4
10
5
6
11
3
2
1
HYEX00373
Figure 2. Left Rear View Mirror Installation.
3.
Install new lockwasher (Figure 2, Item 8) and nut (Figure 2, Item 7) to screw (Figure 2, Item 9).
4.
Install three washers (Figure 2, Item 5) and bracket (Figure 2, Item 4) on handrail (Figure 2, Item 6).
5.
Install two washers (Figure 2, Item 3), nut (Figure 2, Item 2), and cap (Figure 2, Item 1) to bracket (Figure 2,
Item 4).
END OF TASK
FOLLOW-ON MAINTENANCE
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
