Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  876    877    878    879    880  881  882    883    884    885    886
. . . . . .
TM 5-3805-294-23-4
0615
FIELD MAINTENANCE
OVERLOAD ALARM WIRING HARNESS REPLACEMENT
INITIAL SETUP:
Equipment Condition (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Negative battery cable disconnected. (WP 0521)
Cab forward lower armor plate removed.
(Volume 5, WP 0796, Table 2, Item 119)
(WP 0587)
Storage compartment door removed. (WP 0608)
Materials/Parts
Seat removed. (WP 0580)
Tags (Volume 5, WP 0797, Table 1, Item 52)
Cab rear tray removed. (WP 0566)
Tie Wraps (Volume 5, WP 0797, Table 1, Item
56)
Twine (Volume 5, WP 0797, Table 1, Item 58)
Time to Complete
Qty: 15 ft
5.4 Hour(s)
Locknut (Volume 5, WP 0798, Table 1, Item 24)
Qty: 1
Personnel Required
Construction Equipment Repairer 91L (1)
References
TM 5-3805-294-24P: Fig. 145 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
Equipment Condition
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
REMOVAL
WARNING
Ensure electrical power is off prior to working on all electrical connections. Prior to working
on or around vehicle, remove all jewelry, such as rings, ID tags, bracelets, etc. Jewelry, and
tools can catch on equipment, contact positive electrical circuits, and cause a direct short,
severe burns, or electrical shock. Failure to comply may result in injury or death to personnel.
NOTE
Tag and mark wires, connectors, and wiring harnesses prior to removal to ensure proper
installation.
Note position of each tie wrap and remove as required.
0615-1
