TM 5-3805-294-23-4
FIELD MAINTENANCE
CAB FORWARD LOWER ARMOR PLATE REPLACEMENT
INITIAL SETUP:
Tools and Special Tools
Equipment Condition
Tool Kit, General Mechanic's: Automotive (Volume
Machine safely parked and shut down
5, WP 0796, Table 2, Item 119)
(TM 5-3805-294-10). (Volume 5, WP 0794)
Lifting Device, Minimum Capacity 500 lb
Time to Complete
Personnel Required
0.2 Hour(s)
Construction Equipment Repairer 91L (2)
References
TM 5-3805-294-24P: Fig. 137 (Volume 5,
WP 0794)
DA FORM 5988-E or DA FORM 2404 (Volume 5,
WP 0794)
REMOVAL
WARNING
Armor weighs approximately 101 lb (46 kg). Do not attempt to lift or move without the aid of
assistants and suitable lifting device. Failure to comply may result in injury or death to
personnel.
1.
Remove six bolts (Figure 1, Item 1) and washers (Figure 1, Item 2) from armor plate (Figure 1, Item 3) and
machine (Figure 1, Item 4).
0587-1
