TM 5-3805-294-23-4
0588
INSTALLATION - Continued
4
3
2
1
HYEX00351
Figure 2.
Cab Rear Lower Armor Plate Installation.
2.
Install nine screws (Figure 2, Item 1) and washers (Figure 2, Item 2) to armor plate (Figure 2, Item 3) and
machine (Figure 2, Item 4).
END OF TASK
FOLLOW-ON MAINTENANCE
Perform the Standard Follow-On Maintenance Instructions. (Volume 3, WP 0384)
END OF TASK
END OF WORK PACKAGE
0588-3/4 blank
