Figure 4. Hose Installation.
REMOVAL - Continued

Maintenance Manual For Hydraulic Excavator Type 1 With Hydraulic Thumb And Quick Latch -4 Page Navigation
  1150    1151    1152    1153    1154  1155  1156    1157    1158    1159    1160
. .
TM 5-3805-294-23-4
0653
FIELD MAINTENANCE
BOOM UP PRESSURE SENSOR REPLACEMENT
INITIAL SETUP:
Materials/Parts (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Tie Wraps (Volume 5, WP 0797, Table 1, Item
56)
(Volume 5, WP 0796, Table 2, Item 119)
O-ring (Volume 5, WP 0798, Table 1, Item 150)
Cap and Plug Set (Volume 5, WP 0796, Table 2,
Item 55)
Qty: 1
Gloves, Rubber (Volume 5, WP 0796, Table 2,
Item 55)
Personnel Required
Goggles, Industrial (Volume 5, WP 0796, Table 2,
Construction Equipment Repairer 91L (1)
Item 58)
Pan, Drain (Volume 5, WP 0796, Table 2, Item
55)
References
TM 5-3805-294-24P: Fig. 198 (Volume 5,
WP 0794)
Materials/Parts
DA FORM 5988-E or DA FORM 2404 (Volume 5,
Lubricating Oil, Engine OE/HDO 15W-40
WP 0794)
(Volume 5, WP 0797, Table 1, Item 18)
Rags, Wiping (Volume 5, WP 0797, Table 1, Item
34)
Equipment Condition
Tags (Volume 5, WP 0797, Table 1, Item 52)
Machine safely parked and shut down
(TM 5-3805-294-10). (Volume 5, WP 0794)
Negative battery cable disconnected. (WP 0521)
Hydraulic system pressure relieved. (Volume 5,
WP 0767)
Time to Complete
0.3 Hour(s)
REMOVAL
WARNING
LUBRICATING OIL
0653-1
