TM 5-3805-294-23-1
FIELD MAINTENANCE
ABNORMAL ENGINE NOISE
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0363
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0382
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0410
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0414
Test Set, MSD Electronic Systems
Volume 3, WP 0417
(Volume 5, WP 0796, Table 2, Item 116)
Volume 3, WP 0444
Volume 3, WP 0452
Volume 3, WP 0453
Personnel Required
Volume 4, WP 0593
Construction Equipment Repairer 91L (2)
Volume 5, WP 0800
References
Equipment Condition
TM 5-3805-294-10 (Volume 5, WP 0794)
Machine safely parked and shut down. (TM
5-3805-294-10) (Volume 5, WP 0794)
Volume 2, WP 0310
Test Equipment Setup for MSD and Service
Volume 3, WP 0315
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0335
TROUBLESHOOTING PROCEDURE
Table 1. Abnormal Engine Noise.
Test or Inspection
Corrective Action
Malfunction
Check engine oil level.
1.
If engine oil level is low, fill oil
1.
Low Engine Oil
to proper level. (Volume 2,
Level.
(Volume 2, WP 0310)
WP 0310)
2.
If engine oil level is full,
proceed to Malfunction 2.
1.
Turn the key switch to the ON
2.
Engine Oil Pressure
position, START ENGINE (TM
Out of Limits.
5-3805-294-10). (Volume 5,
WP 0794)
2.
Select Readings and select
Connect to Model(s). (Volume
3, WP 0363)
3.
Select Dearborn Protocol
Adapter (DPA 4+) USB for the
Readings Adapter, and select
OK. (Volume 3, WP 0363)
0111-1
