TM 5-3805-294-23-1
FIELD MAINTENANCE
DTC 3511.04 - SENSOR SUPPLY #3 VOLTAGE OUT OF RANGE LOW
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0345
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0362
Accessory Kit, MSD Electronic Equipment
Volume 4, WP 0508
(Volume 5, WP 0796, Table 2, Item 2)
Volume 4, WP 0509
Test Set, MSD Electronic Systems
Volume 4, WP 0511
(Volume 5, WP 0796, Table 2, Item 116)
Volume 5, WP 0800
Personnel Required
Equipment Condition
Construction Equipment Repairer 91L (2)
Machine safely parked and shut down. (Volume 5,
WP 0794)
Test Equipment Setup for MSD and Service
References
ADVISOR. (Volume 3, WP 0375)
TM 5-3805-294-10 (Volume 5, WP 0794)
Troubleshooting Sequence
3511.04
When DTC is Displayed
Whenever the ignition is ON and the error is active.
Related Information
The ECU detects a supply voltage less than 4.59 volts on the Sensor Supply #3 circuit.
The output from this supply comes out of connector J02 of the ECU.
Alarm Level
Warning.
Control Unit Response:
The ECU will try to maintain the engine operating envelope. Engine performance may be affected.
0110-1
