TM 5-3805-294-23-1
FIELD MAINTENANCE
ENGINE EMITS EXCESSIVE BLACK OR GRAY EXHAUST SMOKE
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0362
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0369
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0408
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0429
Test Set, MSD Electronic Systems
Volume 3, WP 0456
(Volume 5, WP 0796, Table 2, Item 116)
Volume 3, WP 0482
Volume 4, WP 0508
Volume 4, WP 0510
Personnel Required
Volume 4, WP 0511
Construction Equipment Repairer 91L (2)
Volume 5, WP 0800
References
Equipment Condition
TM 5-3805-294-10 (Volume 5, WP 0794)
Machine safely parked and shut down (TM
5-3805-294-10). (Volume 5, WP 0794)
Test Equipment Setup for MSD and Service
Volume 3, WP 0329
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0345
TROUBLESHOOTING PROCEDURE
Table 1. Engine Emits Excessive Black or Gray Exhaust Smoke.
Test or Inspection
Corrective Action
Malfunction
Were you referred to this
1.
If you were referred to this
1.
DTC Referral.
procedure while performing
procedure, proceed to
the procedures for a DTC?
Malfunction 3.
2.
If you were not referred to this
procedure, proceed to
Malfunction 2.
1.
Turn key switch to ON position,
2.
Check For Active
but DO NOT START ENGINE
DTCs.
(TM 5-3805-294-10). (Volume
5, WP 0794)
2.
Read DTCs. Note all active
DTCs. (Volume 3, WP 0362)
0117-1
