TM 5-3805-294-23-1
FIELD MAINTENANCE
ENGINE MISFIRES - RUNS IRREGULARLY
INITIAL SETUP:
References (cont.)
Tools and Special Tools
Tool Kit, General Mechanic's: Automotive
Volume 3, WP 0330
(Volume 5, WP 0796, Table 2, Item 119)
Volume 3, WP 0362
Accessory Kit, MSD Electronic Equipment
Volume 3, WP 0363
(Volume 5, WP 0796, Table 2, Item 2)
Volume 3, WP 0364
Test Set, MSD Electronic Systems
Volume 3, WP 0407
(Volume 5, WP 0796, Table 2, Item 116)
Volume 3, WP 0408
Volume 3, WP 0410
Volume 3, WP 0425
Personnel Required
Volume 3, WP 0426
Construction Equipment Repairer 91L (2)
Volume 3, WP 0441
Volume 3, WP 0442
References
Volume 3, WP 0477
TM 5-3805-294-10 (Volume 5, WP 0794)
Volume 3, WP 0481
Volume 4, WP 0508
Volume 5, WP 0800
Equipment Condition
Machine safely parked and shut down (TM
5-3805-294-10). (Volume 5, WP 0794)
Volume 3, WP 0315
Test Equipment Setup for MSD and Service
Volume 3, WP 0321
ADVISOR. (Volume 3, WP 0375)
Volume 3, WP 0328
Volume 3, WP 0329
TROUBLESHOOTING PROCEDURE
Table 1. Engine Misfires - Runs Irregularly.
Test or Inspection
Corrective Action
Malfunction
Were you referred to this
1.
If you were referred to this
1.
DTC Referral.
procedure while performing
procedure, proceed to
the procedures for a DTC?
Malfunction 3.
2.
If you were not referred to this
procedure, proceed to
Malfunction 2.
1.
Turn key switch to ON position,
2.
Check For Active
but DO NOT START ENGINE
DTCs.
(TM 5-3805-294-10). (Volume
5, WP 0794)
0120-1
