Table 1. High-Pressure Fuel Supply System Test - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Remove glow plugs. (Volume
12.
Glow Plugs Indicate
Large Amounts of
3, WP 0433)
Fuel in Combustion
Chamber.
2.
Visually inspect glow plug(s)
1.
If large amounts of fuel is
combustion chamber.
present in any combustion
chamber, replace affected fuel
injector (Volume 3, WP 0408),
then proceed to Malfunction 5.
2.
If large amounts of fuel is not
present in any combustion
chamber, reinstall glow plugs
(Volume 3, WP 0433) , then
proceed to Malfunction 13.
1.
Replace high-pressure fuel
13.
High-Pressure Fuel
Pump Faulty.
pump. (Volume 3, WP 0436)
2.
Turn key switch to ON position,
but DO NOT START ENGINE
(TM 5-3805-294-10). (Volume
5, WP 0794)
3.
Select Readings and select
Connect to Model(s). (Volume
3, WP 0363)
4.
Select Dearborn Protocol
Adapter (DPA 4+) USB for the
Readings Adapter, and select
OK. (Volume 3, WP 0363)
5.
Select Engine Control Unit
(ECU) Only. (Volume 3,
WP 0363)
6.
Under Connected Data Points,
select ECU - (shown with
engine serial number).
(Volume 3, WP 0363)
7.
Under ECU - (shown with
engine serial number), select
ECU - Data List - All. (Volume
3, WP 0363)
8.
Under ECU - Data List - All,
select Fuel Rail Pressure -
Actual. (Volume 3, WP 0363)
0130-7
