TM 5-3805-294-23-1
0130
Table 1. High-Pressure Fuel Supply System Test - Continued.
Test or Inspection
Corrective Action
Malfunction
1.
Turn key switch to ON position,
2.
Check For Active
but DO NOT START ENGINE
DTCs.
(TM 5-3805-294-10). (Volume
5, WP 0794)
2.
Read DTCs. Note all active
DTCs. (Volume 3, WP 0362)
3.
Turn key switch to OFF
1.
If any DTCs are active,
position (TM 5-3805-294-10).
discontinue this
troubleshooting procedure and
(Volume 5, WP 0794)
perform procedure for active
DTCs. Resolve all DTCs
before continuing this
procedure.
2.
If no active DTCs are present,
proceed to Malfunction 3.
1.
Bleed air from fuel system.
3.
Low-Pressure Fuel
System Not Within
(Volume 3, WP 0459)
Specifications.
2.
Perform Low-Pressure Fuel
1.
If passed, proceed to
Supply System Test.
Malfunction 4.
If failed, repair fault found in
2.
Low-Pressure Fuel Supply
System Test. (WP 0131)
Restore machine to original
condition. Clear and refresh
DTCs. (Volume 3, WP 0362)
Start engine(TM
1.
If engine starts, proceed to
4.
Machine Does Not
5-3805-294-10). (Volume 5,
Malfunction 37.
Start.
WP 0794)
2.
If engine does not start,
proceed to Malfunction 5.
1.
Turn key switch to ON position,
5.
Fuel Rail Pressure
but DO NOT START ENGINE
Check With Engine
(TM 5-3805-294-10). (Volume
Cranking.
5, WP 0794)
2.
Select Readings and select
Connect to Model(s). (Volume
3, WP 0363)
3.
Select Dearborn Protocol
Adapter (DPA 4+) USB for the
Readings Adapter, and select
OK. (Volume 3, WP 0363)
0130-2
